Energyra® IconIQ
The future is now
The electrical contacts of the Energyra IconIQ module are integrated on the back (back contact): no ribbons and no wiring at all. There is nothing to cover the cell, not any shade: light absorption is absolutely stretched to the max.
This innovative technology, invented by our partner ISC Konstanz, is reaching even more yield in combination with IconIQ’s smooth, elegant and uninterrupted black design. The black back sheet and frame are the icing on the cake. IconIQ is particularly suitable for residential applications and buildings with a high architectural value, or locations where optimizing power density of the PV system comes first.
A solar module
with a European heart...
Energyra is fully committed to bring the production of solar modules and the associated chain of materials back to Europe. We cannot achieve this by ourselves. That is why we have partnerships with leading European research institutes, such as ISC-Konstanz and TNO. We also have technological partnerships with DSM-Endurans and SPP, to name a few. The IconIQ solar module is the direct result of this. A great mix of European technology, materials and production is no longer a dream. Come, see and touch. We are in Amsterdam!
Back contact Technology by TNO
The module design is based on back contact interconnection, an industrially proven concept that was developed in the Netherlands by ECN (now part of TNO).
Back contact modules realize superior power outputs, because of their low cell-to-module loss factor and their superior robustness against thermo-mechanical stresses. Additionally, they offer an inherent capacity to dissipate heat, which allows them to ‘run cooler’ than conventional tab string or wired modules.
The form factor is more flexible than that of conventional modules, which makes back contact modules easier to integrate. They also facilitate desirable aesthetic designs.
ZEBRA Technology
by
ISC Konstanz
The solar cells in the module that drive its high performance are based on the ‘ZEBRA’ IBC (Interdigitated Back Contact) technology, developed by ISC Konstanz. This lowest cost IBC technology reaches efficiencies of over 24% in production. The current technology even reaches voltages above 700mV, without the need of passivating contacts.
IconIQ will become commercially available in the course of 2022.
But, the future is now: come & see, touch & feel it at Energyra. And fall in love...
Irresistible aesthetics
Powerful performance
The IconIQ module is based on ZEBRA interdigitated back contact (IBC) cells, a concept developed by ISC Konstanz aimed at reducing production cost for high efficiency back contact technologies. The cells have been shown to reach over 24% in production, and while they still likely cost a little more than the industry standard silicon PERC modules they offer further advantages in operation.
“Back contact technology could become mainstream for rooftop, building integration, and for product integration, as there are several advantages that clearly overcompensate past drawbacks,” commented ISC Konstanz’s Radovan Kopecek, "Back contact is offering the unbeaten premium in PV manufacturing nowadays. In the past, one of the major drawbacks has been the higher cost of IBC technology, which we have addressed now with our highly efficient, low-cost ZEBRA cell technology. Energyra proves we can start high volume PV production in the EU, with combining the best technologies of EU´s leading institutes in the near future.”
“The IconIQ solar panel combines two high-quality technologies, and offers many advantages, such as lead-free, solder-free contacting and greatly improved robustness,” says Energyra Europe’s Daniël Kuijk. “Our panel is not only lead-free but also free of fluorine and polyfluoroalkyl substances (PFAS), which is not the case for mainstream solar panels. To achieve something like this, you need the entire value chain.”
The consortium behind the IconIQ module comprises Dutch module manufacturer Energyra, working alongside research institutes TNO (former ECN) and ISC Konstanz.
Image: ISC-Konstanz. A close up of a Zebra-IBC cell. Characterized by the smooth, non-metallized and uninterrupted surface, the backside of the cell is a next era, high-tech silicon product.
Frequently Asked Questions
Its low-temperature coefficient (-0.3%/°C), adds 3% of power, even in average operating conditions.
Moreover, the inverter is switched on earlier in the morning and switched off later in the evening,
thanks to its improved low light performance.
Other family-members
EclectIQ
Full-black
Monocrystalline
When every square meter of roof surface counts (and when doesn’t it) modular efficiency (KWh/m2) is essential. Energyra® ECLECTIQ solar panels offer an unprecedented module efficiency, in addition to great green back contact technology efficiency.
DynamIQ
Lightweight
project PV module
Ultra light solar panel.
From 1.8 kg/m2 and up, depending on the need or application. While maintaining the proven, highest power harvest per m2 (sqft).
Availability of EclectIQ
Our EclectIQ modules are distributed and supported by Rexel to your own installer in the Benelux. Contact your installer for a suitable quotation and simply ask for Energyra PV-modules: they will know exactly what to do.
Do you have specific questions or require industrial or mobile applications outside of the Benelux? Contacting Energyra is always a good idea!
